PLS8239112 High Capacity 7.4V 4400mah Lipo Battery Packs

Name: PLS8239112 High Capacity 7.4V 4400mah Lipo Battery Packs
Brand: PLS Battery Co., Ltd.

PLS8239112-2S is with 8239112(8.2*39*112mm) (T*W*L) battery cells.

It is a 7.4v rechargeable lithium-polymer battery with 4400mah capacity, which is a customized produced lithium pack, used for high output electric devices. Any requirements of customizing size, PCB, wire, connectors of lithium battery packs are welcomed.

Specifications of PLS8239112 High Capacity 7.4V 4400mah Lipo Battery Packs

Item	Rating	Note
Model	PLS8239112-2S	8.239112mm(cell)
Nominal Capacity	4400mAh	Standard discharge, 0.2C discharge, 3.0V cut-off
Nominal Voltage	7.40V
Standard Charge Current	0.2C	0.2C, 8.40V (CC-CV) 0.03C cut off.
Standard Discharge Current	0.2C	0.2C, 6.0V cut off.
Maximum Discharge Current	4400mA	1.0C , Continuous Current
	13200mA	3.0C , Peak Current
Weight	163g
Operating Temperature	0~45℃	Charge
	-20~60℃	Discharge
Storage Temperature	-20~45℃	1month
	-20~35℃	3month
	-20~20℃	1year
Application	Bluetooth, wireless devices, Wearable electronics devices, Scanner, Camera, GPS, monitor, cards...
