PLS653065 3S1P 11.1V 1000Mah Lithium Polymer Battery Pack

Name: PLS653065 3S1P 11.1V 1000Mah Lithium Polymer Battery Pack
Brand: PLS Battery Co., Ltd.

PLS653065-3S with 653065(6.5*30*65mm) (T*W*L) battery cells.

It is a rechargeable lithium polymer battery with 1000mah capacity and 10C high C-rate, which is a customized 11.1V battery pack, used for high output electric devices. We, being one of lithium ion battery manufacturers, welcom uour requirements of customizing size, wire, connectors of lithium battery packs.

Specification of PLS653065 3S1P 11.1V 1000Mah Lithium Polymer Battery Pack

Item	Rating	Note
Model	PLS653065-3S	6.53065mm(cell)
Nominal Capacity	1000mAh	Standard discharge, 0.2C discharge, 3.0V cut-off
Nominal Voltage	11.10V
Standard Charge Current	0.2C	0.2C, 12.60V (CC-CV) 0.03C cut off.
Standard Discharge Current	0.2C	0.2C, 9.0V cut off.
Maximum Discharge Current	10000mA	10C , Continuous Current
	15000mA	15C , Peak Current
Weight	85g
Operating Temperature	0~45℃	Charge
	-20~60℃	Discharge
Storage Temperature	-20~45℃	1month
	-20~35℃	3month
	-20~20℃	1year
Application	UAVs, toys, airplane models, boat models, robots, military equipment, etc.
